E-Glass Fiberglass Woven Roving

short description:

E-glass Fiber Woven Roving is in variety resin strengthen systems, is one of the strongest textile fibers, having greater specific tensile strength than steel wire of the same diameter, at a lower weight.  widely used in hands machanical process and paste the shaping crafts of glass fiber reinforced plastic.

MOQ:10 tons


Product Detail

Product Tags


PROPERTY

• Warp and weft roving aligned in a parallel and flat manner, resulting in uniform tension.
• Densely aligned fibers, resulting in high dimensional stability and making handing easy.
• Good mold ability, fast and complete wet in resins, resulting in high productivity.
• Good transparency and high strength of composite products
• Good mold ability and drapability making handing easy.
• Warp and weft roving aligned in a parallel and flat manner resulting in uniform tension and very little twist.
• Excellent mechanical properties
• Good wet-out in resins.

APPLICATION

•Petrochemical: pipes, tanks, liquefied petroleum gas cylinders
•Transportation: cars, buses, tankers, tanks, liquefied gas cylinders
• Electrical industry: industrial and household appliances, printed circuit boards and electronic equipment shell
•Building materials: Column beam, fence, wave color tile, decorative plate, kitchen
•Machinery industry: aircraft structure, fan blades, firearms parts, artificial bones and teeth
•Science and technology defense: aerospace industry, weapons communications industry; missile satellite, space shuttle, military base, helmet, transformation of the aircraft cab door
• Leisure culture: fishing rod, golf club , Tennis racket, bow and arrow, pole, bowling, swimming pool, snowboard

E-Glass Fiberglass Woven Roving

Item

Tex

Count of cloth

(root/cm)

Unit area mass

(g/m)

Breaking strength(N)

Width(mm)

Wrap yarn

Weft yarn

Wrap yarn

Weft yarn

Wrap yarn

Weft yarn

EWR200 180 180

6.0

5.0

200+15

1300

1100

30-3000
EWR300 300 300

5.0

4.0

300+15

1800

1700

30-3000
EWR400 576 576

3.6

3.2

400±20

2500

2200

30-3000
EWR500 900 900

2.9

2.7

500±25

3000

2750

30-3000
EWR600

1200

1200

2.6

2.5

600±30

4000

3850

30-3000
EWR800

2400

2400

1.8

1.8

800+40

4600

4400

30-3000

PACKING AND STORAGE

· Woven roving could be produced into different widths,each roll is wound on a suitable cardboard tubes with inside diameter of 100mm,then put into a polyethylene bag,
·Fastened the bag entrance and packed into a suitable cardboard box.Upon to customer's request,this product could be shipped either with carton packaging only or with packaging,
·In pallet packaging,the products could be horizontally put on the pallets and fastened with packing straps and shrink film.
· Shipping: by sea or by air
· Delivery Detail:15-20 days after receive the advance payment
