Medium Alkali (C-glass) Fiberglass Roving
Product Introduction
C glass Fiberglass Roving is made of glass balls or waste glass through high-temperature melting, wire drawing, winding, and other processes. The company adopts the crucible wire drawing technology to heat the glass ball to a high enough temperature and then draws different specifications of glass fiber yarn through the platinum-rhodium alloy bushing.
IDENTIFICATION
C glass Fiberglass Roving Product Specifications: (The following are conventional specifications, if you need to customize, please contact the product manager)
APPLICATION
C glass Fiberglass Roving Medium-alkali glass fiber yarn is one of the main raw materials for electrical insulating materials, industrial filter materials, anti-corrosion, moisture-proof, heat-insulating, sound-insulating, shock-absorbing materials, reinforcing materials and other materials, and is widely used in textile wall mesh cloth, grinding wheel reinforcement Mesh, fireproof cloth, filter cloth and other materials.
|
Model |
Ingredient |
Alkali content |
Single fiber diameter |
Number |
Strength |
|
CC11-67 |
C |
6-12.4 |
11 |
67 |
>=0.4 |
|
CC13-100 |
13 |
100 |
>=0.4 |
||
|
CC13-134 |
13 |
134 |
>=0.4 |
||
|
CC11-72*1*3 |
11 |
216 |
>=0.5 |
||
|
CC13-128*1*3 |
13 |
384 |
>=0.5 |
||
|
CC13-132*1*4 |
13 |
396 |
>=0.5 |
||
|
CC11-134*1*4 |
11 |
536 |
>=0.55 |
||
|
CC12-175*1*3 |
12 |
525 |
>=0.55 |
||
|
CC12-165*1*2 |
12 |
330 |
>=0.55 |
PROPERTY
Features of C glass Fiberglass Roving:
1. High filter efficiency
2. Corrosion resistance
3. High-temperature resist
Packing and delivery
| Package height mm (in) |
260(10) |
| Package inside diameter mm(in) |
100(3.9) |
| Package outside diameter mm(in) |
270(10.6) |
| Package Weight kg(lb) |
17(37.5) |
| Number of layers |
3 |
4 |
| Number of doffs per layer |
16 |
|
| Number of doffs per pallet |
48 |
64 |
| Net Weight per pallet kg(lb) |
816(1799) |
1088(2398.6) |
| Pallet Length mm(in) |
1120(44) |
|
| Pallet Width mm(in) |
1120(44) |
|
| Pallet height mm(in) |
940(37) |
1200(47) |
Our company mainly provides the following products and services: C glass Fiberglass Roving, fiberglass direct roving, fiberglass panel roving, fiberglass spray up roving, fiberglass mesh, fiberglass chopped strand mat, fiberglass stitched mat, fiberglass unidirectional fabric, fiberglass biaxial fabric, polyester stitched combo mat, etc., also provides glass fiber Cloth, fiberglass woven roving， fiberglass surface mat, carbon fiber fabric, aramid fiber fabric, epoxy resin, polyester resin and other raw materials, and auxiliary materials, providing customers with production technology consulting and services. The current service industry areas are municipal pipelines, environmental dust, wind power, chemical corrosion, cold chain transport, FRP shipbuilding, pultruded profiles, etc., We have been providing customers with a large number of high-quality fiber-reinforced materials and solutions and obtained their affirmation.
